90 Degree Female RJ45 USB Connector , RJ45 PCB Jack With Led / Emi Tab - Up Shielded

Name: 90 Degree Female RJ45 USB Connector RJ45 PCB Jack With Led Emi Tab Up Shielded
Brand: XINGGE
Price: 1 USD

Brand Name : XINGGE

Certification : ISO9001,SGS,UL,CE,REACH

Place of Origin : Guangdong, China (Mainland)

MOQ : 500 PCS

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 5,000,000pcs/Month

Delivery Time : 10 - 25 work days

Packaging Details : 50 pcs in 1 tray , 10 tray in 1 carton , which is 31.5*24*40 CM , 7.8 KGS (500pcs ) in 1 carton

Tab Direction : Tap Up,Tap Down

Project Application : USB Connector , Networking Solutions

Orientation : 90 Degree , Side Enter

Terminal : Phosphor Copper

LED : Option

Durability : 750 CYCLES MIN

Contact Now

Material:

1. Housing Material: Glass Filled Polyester(UL94V-0),ABS.PBT,NYLON
2. Contact Material: Phosphor Bronze t=0.35mm.
3. Plating: Contact Area-Selectine Gold Plating.
4. Shield: Copper Alloy 0.20 Thickness Plating Ni.
5. LED: Option

Feature:

1. Reduce EMI Radiation, Improve EMI Performance.
2. Designed For Network Interface Card Application.
3. Designed To Meet IEEE802.3u Requirement.
4. Suitable for CAT 3, 5, 6 UTP cable or better

Electrical:

Current Rating 1.5 AMP
Voltage Rating 1.25 VAC
Insulation Resistance 500MΩMin
Withstanding Resistance 1000VAC RMS 50Hz or 60Hz 1 Minute
Contact Resistance 30mΩMax

Mechanical:

1. Durability:750 CYCLES MIN

2. PCB Rentention pre-solder:1LB MIN

Environmental:

1. Storage Temperature -40°C~80°C Relative Humidity <80%.
2. Opration Temperature 0°C~+70°C

Lead-free process,compliant RoHS

90 Degree Female RJ45 USB Connector , RJ45 PCB Jack With Led / Emi Tab - Up Shielded
