8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector Surface Mount

Product Categories

ZHEJIANG SAK ELECTRONICS CO.,LTD

Contact Now

8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector Surface Mount

Name: 8P8C 2 Port RJ45 Modular Jack Female To Female RJ45 Shielded Connector Surface Mount
Brand: XINGGE
Price: 1 USD

Brand Name : XINGGE

Certification : ISO9001,SGS,UL,CE,REACH

Place of Origin : Guangdong, China (Mainland)

MOQ : 500 PCS

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 5,000,000pcs/Month

Delivery Time : 3-30 work days

Packaging Details : 300 pcs in 1 tray , 36 tray ( 2500pcs ) in carton ;

Application : PCB

OEM/ODM : OEM Service Offered Design Service Offered Buyer Label Offered

Gender : Female

Main Products : Magjack , RJ45 Jack , RJ45 Connector , RJ45 , Rj45 Socket

Project Application : Networking Solutions

Gold-plated : Fu" , 1u" , 3u" , 6u" , 15u" , 30u" , 50u"

Contact Now

8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector

ELECTRICAL:

1. Voltage Rating:125 Vac Rms.
2. Current Rating:1.5 Amp.
3. Contact Resistance:50 Milliohms Max.
4. Insulation Resistance:500 Megohms Min @ 500v Dc.
5. Dielectric Withstanding
Resistance:1000v Ac Rms 50hz. 1min.

MECHNICAL:

1. Housing Material:Glass Filled Polyester(Ul94v-0).
2. Contact Material:Phosphor Bronze T=0.46mm (C5 100).
3. Plating:Glod Plating Over Nickel.
4. Durrability:750 Cycles Min.
5. Pcb Retention Pre-Solder:1 Lb Min.
6. Pcb Retention Post-Solder:10 Lb Min.

ENVIRONMENTAL:

1. Storage:-40℃ To +85℃.
2. Operation:0℃ To 70℃
3. Wave Solder Temperture:230-250℃(5-10 Seconds)

MATES WITH MODULAR PLUG CONFORMING TO FCC PART F.

Service

Our Offer good pre-sales & after-sales service &Strong technical support

1. New Project: Strong technical and ideal support your new design

2. Existing projects: Try to help customer to save the cost to offer the good quality product and save time.

3. Free Samples:3-5 PCS of each part number.

4. Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.

5. Customer complaint:24-48 hours reply 8D report.

6. Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,or repair kits if

customers are not satisfied)

8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector Surface Mount

Product Tags:

modular jack rj45

rj45 modular connector

China 8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector Surface Mount wholesale

8P8C 2 Port RJ45 Modular Jack , Female To Female RJ45 Shielded Connector Surface Mount Images
